CM20
The Yealink CM20 ceiling mic features an 83mm low-profile design. Equipped with 16 omnidirectional units, it delivers unparalleled pro-level audio clarity. With AI Dynamic Noise Reduction and AI Reverberation Suppression, the CM20 automatically adapts to room conditions for effective noise and echo reduction. Integrated with DSP, the CM20 offers plug-and-play functionality with Yealink MVC systems, eliminating the need for an additional DSP device.
The Yealink CM20 ceiling mic features an 83mm low-profile design. Equipped with 16 omnidirectional units, it delivers unparalleled pro-level audio clarity. With AI Dynamic Noise Reduction and AI Reverberation Suppression, the CM20 automatically adapts to room conditions for effective noise and echo reduction. Integrated with DSP, the CM20 offers plug-and-play functionality with Yealink MVC systems, eliminating the need for an additional DSP device.
Advanced Microphone Array
SkySound CM20 is equipped with 16 omnidirectional units, providing unparalleled audio clarity across 8 independent pickup zones.
SkySound CM20 is equipped with 16 omnidirectional units, providing unparalleled audio clarity across 8 independent pickup zones.
Superior Coverage
Effectively covers up to 60 m2, with a high-quality 30 m2 full-duplex audio capture, ideal for medium to large spaces.
Effectively covers up to 60 m2, with a high-quality 30 m2 full-duplex audio capture, ideal for medium to large spaces.
Intelligent Sound Processing
Integrates Yealink's advanced noise, echo, and reverberation cancellation technologies for crystal-clear audio in every meeting.
Integrates Yealink's advanced noise, echo, and reverberation cancellation technologies for crystal-clear audio in every meeting.
Intelligent Tracking
Features 8 beam outputs for precise speaker tracking and integrates with room cameras for enhanced camera tracking, enriching meeting engagement.
Features 8 beam outputs for precise speaker tracking and integrates with room cameras for enhanced camera tracking, enriching meeting engagement.
In-built DSP for Simplicity
Equipped with an integrated DSP, SkySound CM20 offers plug-and-play functionality with Yealink MVC systems, removing the need for external audio processing.
Equipped with an integrated DSP, SkySound CM20 offers plug-and-play functionality with Yealink MVC systems, removing the need for external audio processing.
Network and Deployment Efficiency
Supports AES67 for easy integration into audio networks. PoE enabled, requiring just one Ethernet cable for power and audio.
Supports AES67 for easy integration into audio networks. PoE enabled, requiring just one Ethernet cable for power and audio.
Versatile Ceiling Integration
Offers various installation options, including in-ceiling, pendant, and on-ceiling, for effortless setup and integration.
Offers various installation options, including in-ceiling, pendant, and on-ceiling, for effortless setup and integration.
Elegant and Unobtrusive Design
Includes a removable magnetic suction mesh cover, adding a touch of sophistication while being discreet and easy to maintain.
- Advanced Microphone Array
- Superior Coverage
- Intelligent Sound Processing
- Intelligent Tracking
- In-built DSP for Simplicity
- Network and Deployment Efficiency
- Versatile Ceiling Integration
- Elegant and Unobtrusive Design
Audio Specifications
- Frequency Response: 120Hz-16kHz
- Maximum SPL: 122dBSPL
- Signal Noise Ratio: 94dBSPL @1kHz A-Weight
- Sensitivity: 0 dBV/Pa 94dBSPL@1kHZ
- Microphone: 16 omni-direction microphone
- AEC Channel: 1 channel internal
Package Content
- SkySound CM20 Microphone
- White Mesh Cover (Black Optional)
- Quick Start Guide
- Assembly Fixing Bracket
- Dust Cover
- Length-Adjustable Pole (Optional)
- Bracing Bridge*1 pair
- Suspend Pole Adapter (Optional)
- Expansion Bolt*6 (φ6 * 30 mm, white, Polyamide)
- Self-tapping Screw*6 (T4*30mm)
- Machine Screw*5 (3*6PMOZN3+)
- Bracing Bredge Screw*20 (M3*6PWMHOZN3)
Physical Features
- Operating Temperature: 0-50℃
- Storage Temperature: 0-70℃
- Operating Humidity: 5%~90%
- Continuous Power: 5.7W
- Peak Power: 9W
- Interface: 1*RJ-45
- Power Supply: PoE (IEEE 802.3af, class 3)
Product Specifications
- Size:
- Φ223*H83mm (with cover mesh)
- Φ215*H81mm (without cover mesh)
- Weight: 615g
- Product Color: Pearl Light Gray
- Product Materials: ABS+PC&iron mesh
Logistic Information
- Box Size: 398 mm*310 mm*135mm
- N.W/CTN: 2.462kg
- G.W/CTN: 3.078kg
Includes a removable magnetic suction mesh cover, adding a touch of sophistication while being discreet and easy to maintain.
- Advanced Microphone Array
- Superior Coverage
- Intelligent Sound Processing
- Intelligent Tracking
- In-built DSP for Simplicity
- Network and Deployment Efficiency
- Versatile Ceiling Integration
- Elegant and Unobtrusive Design
Audio Specifications
- Frequency Response: 120Hz-16kHz
- Maximum SPL: 122dBSPL
- Signal Noise Ratio: 94dBSPL @1kHz A-Weight
- Sensitivity: 0 dBV/Pa 94dBSPL@1kHZ
- Microphone: 16 omni-direction microphone
- AEC Channel: 1 channel internal
Package Content
- SkySound CM20 Microphone
- White Mesh Cover (Black Optional)
- Quick Start Guide
- Assembly Fixing Bracket
- Dust Cover
- Length-Adjustable Pole (Optional)
- Bracing Bridge*1 pair
- Suspend Pole Adapter (Optional)
- Expansion Bolt*6 (φ6 * 30 mm, white, Polyamide)
- Self-tapping Screw*6 (T4*30mm)
- Machine Screw*5 (3*6PMOZN3+)
- Bracing Bredge Screw*20 (M3*6PWMHOZN3)
Physical Features
- Operating Temperature: 0-50℃
- Storage Temperature: 0-70℃
- Operating Humidity: 5%~90%
- Continuous Power: 5.7W
- Peak Power: 9W
- Interface: 1*RJ-45
- Power Supply: PoE (IEEE 802.3af, class 3)
Product Specifications
- Size:
- Φ223*H83mm (with cover mesh)
- Φ215*H81mm (without cover mesh)
- Weight: 615g
- Product Color: Pearl Light Gray
- Product Materials: ABS+PC&iron mesh
Logistic Information
- Box Size: 398 mm*310 mm*135mm
- N.W/CTN: 2.462kg
- G.W/CTN: 3.078kg
